EcooGraphix 2400dpi Thermal Computer To Plate Making Machine CTP Machine / Platesetter

Name: EcooGraphix 2400dpi Thermal Computer To Plate Making Machine CTP Machine Platesetter
Brand: EcooGraphix
Price: 1 USD

Wholesale EcooGraphix 2400dpi Thermal Computer To Plate Making Machine CTP Machine / Platesetter from china suppliers

Brand Name : EcooGraphix

Model Number : Ecoosetter T-400

Certification : CE, ISO900

Place of Origin : CHINA

MOQ : 1SET

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 1000 SETS/YEAR

Delivery Time : 30days

Packaging Details : Standard Exporting Wooden Box

Product name : Computer to Plate Making Machine

Exposing Mothod : External Drum

Plate Sizes : Max.800mm x 660mm Min. 400mm x 300mm

Plate Thickness : 0.15mm to 0.30mm

Resolution : 2400dpi

Machine Size : 1900x1200x1000(WxLxH)mm

Contact Now

Product Description

EcooGraphix 2400dpi Thermal Computer To Plate Making Machine CTP Machine / Platesetter

Thermal-CTP T-400 series, most popular CTP, one of the best seller, suitable for middle/small printing factory.

Thermal-CTP T-400 series is the first Prepress necessity of quick short-run offset printing. It can output the images on the computer to printing CTP plate directly through the CTP machine and save the film and labor.

EcooGraphix T-400 Series Thermal CTP Specifications
Model	T-400F	T-400S	T-400E
Imaging System	48 channel	32 channel	24 channel
Output Speed	28pph	22pph	16pph
	800mm x 600mm / 2400dpi
Plate Size	Max. 800 x 690mm Min. 400mm x 300mm
Plate Thickness	0.15mm to 0.30mm
Resolution	2400dpi
Weight	800KG
Repeatability	±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23ºC and humidity of 60%)
Machine Size (WxLxH)mm	1900×1200×1000mm(W×D×H)
Power Supply	single-phase: 260AC, +6%-10%; Power Conumption: 4KW
Environment	recommended: 21-25ºC, Allowed temperature:15-30ºC, Humidity: 40-70%RH

Features:

-Little space occupaid, more flexible

-Small volume, high stability and perfect output quality

-Different speed setting to satisfy different demanding.

EcooGraphix 2400dpi Thermal Computer To Plate Making Machine CTP Machine / Platesetter

1. What are your main products?
Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP and CTCP, FlexoCTP, Processor, Offset Plates, inks, blankets, postpress packing equipments and so on.
There are over 3000sets CTPs installed worldwide. Our partners in USA, Canada, Mexico, Colombia, Turkey, Hungary, South Africa and so on are very pleased with our technician support service and product performance.
We also have five offset plates production lines producing the thermal CTP plate(single and double layers), positive CTCP plates(single and double layers) and Chemistry free CTP plate.
You can get the prepress equipments and consumables all in one and no worry about the after-sales service from our company.

2. Where is your factory?
Our CTP machine factory is located in Hangzhou city, which is about 1.5 hour by train from Shanghai.
You are warmly welcomed to visit our factory!

3. What is your warranty for the CTPs?
Three years' Laser Head and main spare parts for the CTP, one year for the processor.

4. What is the Lead Time?
Usually 20-30 days, and we will try our best to meet your demands.

5. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose.

6. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
