A0 Carton Paper Sheet UV Spot Varnish Coating Polishing Machine HIS1450

Name: A0 Carton Paper Sheet UV Spot Varnish Coating Polishing Machine HIS1450
Brand: ECOOGRAPHIX
Price: 1 USD

Wholesale A0 Carton Paper Sheet UV Spot Varnish Coating Polishing Machine HIS1450 from china suppliers

Brand Name : ECOOGRAPHIX

Certification : CE

Place of Origin : China

MOQ : 1SET

Price : Negotiable

Supply Ability : 500SETS

Delivery Time : 30DAYS

Packaging Details : Standard Export Packing

Coating media : Water-base varnish, UV varnish

Max coating thickness : 0.025mm

Sheet thickness : 128-600gsm

Min sheet size : 350X460mm

Max sheet size : 1100x1450mm

Model Number : HIS1450

Payment Terms : L/C,T/T

Max coating size : 1090x1440mm

Contact Now

A0 Carton Paper Sheet UV Spot Varnish Coating Polishing Machine HIS1450

EcooGraphix is a professional supplier of eco-friendly paper processing machines and paper products. Following the enterprise development mission of “Create Value for Customers".

HIS1450 processes the paper or printed paper sheets as raw materials, automatically conveyed through the machine to complete the functions of top card pasting ,top folding, tube forming and gluing, hole punching, bottom folding, placing the bottom reinforced card and pasting, bottom sealing and gluing, and finally outputting a complete square-bottom paper bag machine (excluding processing the handle rope).

The TB-S series is has a straight line structure both for pasting the cardboard at the bag mouth and pasting the cardboard at the bag bottom, which is flexible placement and save space.

Technical Specifications

High Speed UV Spot and Overall Varnish Coating Machine
Model	Ecoo HIS-1450
Max.sheet size	1100x1450mm
MIN.sheet size	350X460mm
Max.coating size	1090x1440mm
Coating Media	Water-base varnish, UV varnish
Max coating thickness	0.025mm
Sheet thickness	128-600gsm
Coating registration accuracy	±0.2mm
Production speed	6200sheets/hour
Weight	9500kgs
Dimension	12230x3100x1844mm
Power	57KW(E) 47KW(W)
Remark: Production speed depending on sheet weight, size and quality
